29004Tube clamps cross, plastic |
go back |
|
Item description/product images |
|
|
DescriptionMaterial:Thermoplastic.
DIN 7984 screws and DIN 985 nuts steel.Version:Black.
Screws and nuts electro zinc-plated.Note:These cross clamps are for 30 mm square and round tubes. Use reducer sleeves 209040 or 29042 if smaller tubes are to be clamped or a conversion from round to square tubes is required.On request:Plastic clamping levers for tightening.Accessory:- Reducer sleeves 29040 and 29042
- Round and square tubes 29050Special features: DownloadHere is all the information as a PDF datasheet:
Are you looking for CAD data? These can be found directly in the product table.
|
Order No.
| A | B | CAD | Acc. | Price | Order |
|---|
| 29004-3030 | 30 | 30 |  |  | on request | |
