Energy chains, plastic inner height 12 mm, closed

80850

Energy chains, plastic inner height 12 mm, closed

Products
- Product overview
  - Electromechanical
    - Connectors Energy chains
      - Energy chains
        Energy chains, plastic inner height 12 mm, closed

Item description/product images

DescriptionMaterial:Polyamide fibreglass reinforced.Version:Black. Closed.Note:Energy supply chains for safe guiding of flexible electric and data cables as well as pneumatic and hydraulic hoses. The modularly constructed chains can be easily shortened or extended.

The material is UV-resistant and therefore also suitable for outdoor applications.Technical data:Technical features in unsupported areas:
Speed: 10 m/s
Acceleration: 50 m/s²Temperature range:-30°C to +125°CSpecial features:

RoHS

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet 80850 Energy chains, plastic inner height 12 mm, closed

Technical note on energy supply chains

Drawings

Energy chains, plastic inner height 12 mm, closed

Energy chains, plastic inner height 12 mm, closed

Item selection/filter

Order No.	B	B1	H	H1	L	E	M	N	R	No. of links	Approx. weight kg/m	Connecting element	CAD	Acc.	Price	Order
80850-120120180	12	18	12	15	1003	51	95	45	18	59	0,13	80850-01-12012			on request
