        Centring pins for aligning hole

Item description/product images

DescriptionMaterial:Steel.Version:Case-hardened.
Toleranced diameter ground.Note:These centring pins are suitable for the aligning holes of our workholding elements 01263, 01265 and 01850.Special features:

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet 03112 Centring pins for aligning hole

267 kB

Drawings

Item selection/filter

	20 25	75 89 125				Reset
Order No.	D	L	CAD	Acc.	Price	Order
03112-20075	20	75			on request
03112-20089	20	89			on request
03112-25125	25	125			on request
