07304-02Split lock washer, steel |
go back |
|
Item description/product images |
|
|
DescriptionMaterial:Split lock washer, steel.Version:Steel with zinc flake coating.Note:Split lock washers are special lock washers that have been developed for high load screw connections and offer a high degree of security.Special features: DownloadHere is all the information as a PDF datasheet:
Are you looking for CAD data? These can be found directly in the product table.
|
| | | -
- 0,8
- 1
- 1,3
- 1,6
- 1,8
- 2,1
- 2,4
- 2,8
- 3,2
- 1,2
- 2
- 2,5
- 3,5
- 4,5
| -
- 4,1
- 5,1
- 6,1
- 8,1
- 10,2
- 12,2
- 14,6
- 16,2
- 18,2
- 20,2
| -
- 7,6
- 9,2
- 11,8
- 14,8
- 18,1
- 21,1
- 24,1
- 27,4
- 29,4
- 33,6
- 7
- 8,8
- 9,9
- 12,7
- 16,1
- 18,3
- 24,6
- 30,6
| -
- 0,8
- 1
- 1,3
- 1,6
- 1,8
- 2,1
- 2,4
- 2,8
- 3,2
- 1,2
- 2
- 2,5
- 3,5
- 4,5
| -
- M4
- M5
- M6
- M8
- M10
- M12
- M14
- M16
- M18
- M20
| | | | Reset |
|---|
| Order No. | Version 1 | C | D
| D1 | thickness | for
screws
| CAD | Acc. | Price | Order |
|---|
| 07304-02-004 | standard | 0,8 | 4,1 | 7,6 | 0,8 | M4 |  | | on request | | | 07304-02-005 | standard | 1 | 5,1 | 9,2 | 1 | M5 | | | on request | | | 07304-02-006 | standard | 1,3 | 6,1 | 11,8 | 1,3 | M6 | | | on request | | | 07304-02-008 | standard | 1,6 | 8,1 | 14,8 | 1,6 | M8 | | | on request | | | 07304-02-010 | standard | 1,8 | 10,2 | 18,1 | 1,8 | M10 | | | on request | | | 07304-02-012 | standard | 2,1 | 12,2 | 21,1 | 2,1 | M12 | | | on request | | | 07304-02-014 | standard | 2,4 | 14,6 | 24,1 | 2,4 | M14 | | | on request | | | 07304-02-016 | standard | 2,8 | 16,2 | 27,4 | 2,8 | M16 | | | on request | | | 07304-02-018 | standard | 2,8 | 18,2 | 29,4 | 2,8 | M18 | | | on request | | | 07304-02-020 | standard | 3,2 | 20,2 | 33,6 | 3,2 | M20 | | | on request | | | 07304-02-104 | for cap screws | 1,2 | 4,1 | 7 | 1,2 | M4 | | | on request | | | 07304-02-105 | for cap screws | 1,6 | 5,1 | 8,8 | 1,6 | M5 | | | on request | | | 07304-02-106 | for cap screws | 1,6 | 6,1 | 9,9 | 1,6 | M6 | | | on request | | | 07304-02-108 | for cap screws | 2 | 8,1 | 12,7 | 2 | M8 | | | on request | | | 07304-02-110 | for cap screws | 2,5 | 10,2 | 16,1 | 2,5 | M10 | | | on request | | | 07304-02-112 | for cap screws | 2,5 | 12,2 | 18,3 | 2,5 | M12 | | | on request | | | 07304-02-116 | for cap screws | 3,5 | 16,2 | 24,6 | 3,5 | M16 | | | on request | | | 07304-02-120 | for cap screws | 4,5 | 20,2 | 30,6 | 4,5 | M20 | | | on request | |
