Grub screw with hexagon socket and pointed end DIN EN ISO 4027
 07166

Grub screw with hexagon socket and pointed end DIN EN ISO 4027

 go back

Item description/product images
DescriptionMaterial:Steel or stainless steel A2.Version:Steel class 45 H, black.
Stainless steel A2-70, bright.Note:By M4x5, M5x5, M5x6, M6x6, M8x8, M10x10 the point angle is 120°.
DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.
Datasheet 07166 Grub screw with hexagon socket and pointed end DIN EN ISO 4027 177 kB
Grades 124 kB
Overview of standards for fasteners 687 kB

Drawings

Grub screw with hexagon socket and pointed end DIN EN ISO 4027

Overview of items (compressed)

 Item selection/filter


  •
  • steel
  • stainless steel

  •
  • M3
  • M4
  • M5
  • M6
  • M8
  • M10

  •
  • -
  • 1,5
  • 2
  • 2,5

  •
  • 5
  • 6
  • 8
  • 10
  • 12
  • 16
  • 20
  • 25
  • 14
  • 30
  • 35
  • 40
  • 45
  • 50
  • 60
  • 70
  • 80

  •
  • 1,2
  • 1,5
  • 2
  • 3
  • 4
  • 6

  •
  • 1,5
  • 2
  • 2,5
  • 3
  • 4
  • 5

Reset
Order No.Material

D1D2LTSWCADAcc.PriceOrder
07166-03X5steelM3-51,21,5  on request
07166-03X6steelM3-61,21,5  on request
07166-03X8steelM3-81,21,5  on request
07166-03X10steelM3-101,21,5  on request
07166-03X12steelM3-121,21,5  on request
07166-03X16steelM3-161,21,5  on request
07166-03X20steelM3-201,21,5  on request
07166-04X5steelM4-51,52  on request
07166-04X6steelM4-61,52  on request
07166-04X8steelM4-81,52  on request
07166-04X10steelM4-101,52  on request
07166-04X12steelM4-121,52  on request
07166-04X16steelM4-161,52  on request
07166-04X20steelM4-201,52  on request
07166-04X25steelM4-251,52  on request
07166-05X5steelM5-522,5  on request
07166-05X6steelM5-622,5  on request
07166-05X8steelM5-822,5  on request
07166-05X10steelM5-1022,5  on request
07166-05X12steelM5-1222,5  on request
07166-05X14steelM5-1422,5  on request
07166-05X16steelM5-1622,5  on request
07166-05X20steelM5-2022,5  on request
07166-05X25steelM5-2522,5  on request
07166-05X30steelM5-3022,5  on request
07166-06X6steelM61,5623  on request
07166-06X8steelM61,5823  on request
07166-06X10steelM61,51023  on request
07166-06X12steelM61,51223  on request
07166-06X16steelM61,51623  on request
07166-06X20steelM61,52023  on request
07166-06X25steelM61,52523  on request
07166-06X30steelM61,53023  on request
07166-06X35steelM61,53523  on request
07166-06X40steelM61,54023  on request
07166-06X45steelM61,54523  on request
07166-08X8steelM82834  on request
07166-06X50steelM61,55023  on request
07166-06X60steelM61,56023  on request
07166-08X10steelM821034  on request
07166-08X12steelM821234  on request
07166-08X14steelM821434  on request
07166-08X16steelM821634  on request
07166-08X20steelM822034  on request
07166-08X25steelM822534  on request
07166-08X30steelM823034  on request
07166-08X35steelM823534  on request
07166-08X40steelM824034  on request
07166-08X45steelM824534  on request
07166-08X50steelM825034  on request
07166-08X60steelM826034  on request
07166-10X10steelM102,51045  on request
07166-10X12steelM102,51265  on request
07166-10X16steelM102,51665  on request
07166-10X20steelM102,52065  on request
07166-10X25steelM102,52565  on request
07166-10X30steelM102,53065  on request
07166-10X35steelM102,53565  on request
07166-10X40steelM102,54065  on request
07166-10X45steelM102,54565  on request
07166-10X50steelM102,55065  on request
07166-10X60steelM102,56065  on request
07166-10X70steelM102,57065  on request
07166-10X80steelM102,58065  on request
07166-103X5stainless steelM3-51,21,5  on request
07166-103X6stainless steelM3-61,21,5  on request
07166-103X8stainless steelM3-81,21,5  on request
07166-103X10stainless steelM3-101,21,5  on request
07166-103X12stainless steelM3-121,21,5  on request
07166-103X16stainless steelM3-161,21,5  on request
07166-103X20stainless steelM3-201,21,5  on request
07166-104X5stainless steelM4-51,52  on request
07166-104X6stainless steelM4-61,52  on request
07166-104X8stainless steelM4-81,52  on request
07166-104X10stainless steelM4-101,52  on request
07166-104X12stainless steelM4-121,52  on request
07166-104X16stainless steelM4-161,52  on request
07166-104X20stainless steelM4-201,52  on request
07166-104X25stainless steelM4-251,52  on request
07166-105X5stainless steelM5-522,5  on request
07166-105X6stainless steelM5-622,5  on request
07166-105X8stainless steelM5-822,5  on request
07166-105X10stainless steelM5-1022,5  on request
07166-105X12stainless steelM5-1222,5  on request
07166-105X14stainless steelM5-1422,5  on request
07166-105X16stainless steelM5-1622,5  on request
07166-105X20stainless steelM5-2022,5  on request
07166-105X25stainless steelM5-2522,5  on request
07166-105X30stainless steelM5-3022,5  on request
07166-106X6stainless steelM61,5623  on request
07166-106X8stainless steelM61,5823  on request
07166-106X10stainless steelM61,51023  on request
07166-106X12stainless steelM61,51223  on request
07166-106X16stainless steelM61,51623  on request
07166-106X20stainless steelM61,52023  on request
07166-106X25stainless steelM61,52523  on request
07166-106X30stainless steelM61,53023  on request
07166-106X35stainless steelM61,53523  on request
07166-106X40stainless steelM61,54023  on request
07166-106X45stainless steelM61,54523  on request
07166-106X50stainless steelM61,55023  on request
07166-106X60stainless steelM61,56023  on request
07166-108X8stainless steelM82834  on request
07166-108X10stainless steelM821034  on request
07166-108X12stainless steelM821234  on request
07166-108X14stainless steelM821434  on request
07166-108X16stainless steelM821634  on request
07166-108X20stainless steelM822034  on request
07166-108X25stainless steelM822534  on request
07166-108X30stainless steelM823034  on request
07166-108X35stainless steelM823534  on request
07166-108X40stainless steelM824034  on request
07166-108X45stainless steelM824534  on request
07166-108X50stainless steelM825034  on request
07166-108X60stainless steelM826034  on request
07166-110X10stainless steelM102,51045  on request
07166-110X12stainless steelM102,51265  on request
07166-110X16stainless steelM102,51665  on request
07166-110X20stainless steelM102,52065  on request
07166-110X25stainless steelM102,52565  on request
07166-110X30stainless steelM102,53065  on request
07166-110X35stainless steelM102,53565  on request
07166-110X40stainless steelM102,54065  on request
07166-110X45stainless steelM102,54565  on request
07166-110X50stainless steelM102,55065  on request
07166-110X60stainless steelM102,56065  on request
07166-110X70stainless steelM102,57065  on request
07166-110X80stainless steelM102,58065  on request
