Spring plungers with hexagon socket and ball, stainless steel, inch

03035 inch

Spring plungers with hexagon socket and ball, stainless steel,...

Products
- Product overview
  - norelem inch
    - Spring plungers Indexing plungers Stops Centring/positioning components Ball lock pins T-slot nuts - inch
      - Spring plungers - inch
        Spring plungers with hexagon socket and ball, stainless steel, inch

Item description/product images

Show/filter all items

DescriptionMaterial:

Sleeve 1.4305.
Ball 1.4034.
Spring 1.4310.

Version:Bright. Ball hardened.Note:For the inch series, dimension D and S are in inches, all other dimensions are in mm.Special features:

Stainless steel

DownloadHere is all the information as a PDF datasheet:

Are you looking for CAD data? These can be found directly in the product table.

Datasheet 03035 inch Spring plungers with hexagon socket and ball, stainless steel, inch

Drawings (total overview)

Spring plungers with hexagon socket and ball, stainless steel, inch

Spring plungers with hex socket and ball, stainless steel, standard spring force, inch

More information

Drawings

Spring plungers with hex socket and ball, stainless steel, standard spring force, inch

Item selection/filter

	1/4-28 1/4-20 5/16-18 3/8-16 1/2-13 5/8-11	3,5 5 6 8 10	1 1,5 2 2,5 3,5	15 18 23 26 33	1/8 5/32 3/16 7/32 5/16	9 15 20 30 65	13 30 35 55 125				Reset
Order No.	D	D1	H	L	S	Spring force initial pressure F1 approx. N	Spring force final pressure F2 approx. N	CAD	Acc.	Price	Order
03035-AJ	1/4-28	3,5	1	15	1/8	9	13			on request
03035-A2	1/4-20	3,5	1	15	1/8	9	13			on request
03035-A3	5/16-18	5	1,5	18	5/32	15	30			on request
03035-A4	3/8-16	6	2	23	3/16	20	35			on request
03035-A5	1/2-13	8	2,5	26	7/32	30	55			on request
03035-A6	5/8-11	10	3,5	33	5/16	65	125			on request

Spring plungers with hex socket and ball, stainless steel, strong spring force, inch

More information

Drawings

Spring plungers with hex socket and ball, stainless steel, strong spring force, inch

Item selection/filter

	1/4-28 1/4-20 5/16-18 3/8-16 1/2-13 5/8-11	3,5 5 6 8 10	1 1,5 2 2,5 3,5	15 18 23 26 33	1/8 5/32 3/16 7/32 5/16	28 47 66 90	40 73 100 120 180				Reset
Order No.	D	D1	H	L	S	Spring force initial pressure F1 approx. N	Spring force final pressure F2 approx. N	CAD	Acc.	Price	Order
03035-2AJ	1/4-28	3,5	1	15	1/8	28	40			on request
03035-2A2	1/4-20	3,5	1	15	1/8	28	40			on request
03035-2A3	5/16-18	5	1,5	18	5/32	47	73			on request
03035-2A4	3/8-16	6	2	23	3/16	66	100			on request
03035-2A5	1/2-13	8	2,5	26	7/32	66	120			on request
03035-2A6	5/8-11	10	3,5	33	5/16	90	180			on request
